Afandi Solar Shield™ Twin-Core Copper Cable Gray – 2×6mm² شريط مبروم للطاقة الشمسية رمادي
Categories :
Wires & CablesTags :
100% original guarantee
Return within 30days
Free delivery on all orders
Afandi Solar Shield™ Twin-Core Copper Cable Gray – 2×6mm² شريط مبروم للطاقة الشمسية رمادي
| Attribute | Details |
|---|---|
| Cable Type | Twin-core solar cable |
| Conductor Material | High-purity stranded copper |
| Cross-Section Area | 6mm² per core |
| Number of Cores | 2 (Red for Positive, Black for Negative) |
| Rated Voltage | 600/1000V AC or 1800V DC |
| Current Capacity | Approx. 50–60A |
| Insulation Material | XLPE or similar, flame-retardant, halogen-free |
| Outer Sheath | UV-resistant, weatherproof, fire-resistant |
| Temperature Range | –40°C to +90°C (operating); up to +120°C (short circuit) |
| Fire Safety | Flame-retardant, low smoke, halogen-free |
| Compliance | IEC 62930 / EN 50618 / IEC 60332 / IEC 60754 / TÜV / RoHS |
| Application | Solar panel wiring, inverters, battery banks, charge controllers |
| Brand | Afandi |
